4. Wiring
4.1 Wiring
4.1.1 Installation method of VFD keypad to panel
1) Separate the Keypad from case
Pressing the upper locking hook of
keypad, pull it up.
2) Connection
As showing figure, Connect cable between
keypad(RJ45 port) and logic box(RJ45 port).
