Adtech iMASTER – A1 Series - Fault Functions

A1-User’s Manual
７１
8.1.18 Fault functions
No.
Name
Change during
operation
Range
Default
Page
31.01
External event 1 source
-
0. Active
1. Inactive
2. DI1
3. DI2
4. DI3
5. DI4
6. DI5
7. DI6
8. DI7
9. DI8
1
136
31.02
External event 2 source
-
1
136
31.03
External event 3 source
-
1
136
31.04
External event 4 source
-
1
136
31.05
External event 5 source
-
1
136
31.06
Fault reset selection
X
0. Not Selected
1. Selected
2. DI1
3. DI2
4. DI3
5. DI4
6. DI5
7. DI6
8. DI7
9. DI8
7
136
31.07
Restart mode selection
X
0. No Restart
1. Restart from 0Hz
2. Resume at frequency
corresponding motor speed
3. Resume at motor speed, then
decelerated stop
0
137
31.08
Alarm relay operation mode
X
0. Inactive for the Under Voltage trip
signal
1. Inactive during auto reset
2. Active every trip
3. Inactive during auto reset (Only
active for the Under Voltage trip
signal endlessly)
0
137
31.09
Restart delay time
X
0.3 to 10.0 [Sec]
1.0 Sec
137
31.10
Automatic reset item 1
X
0x00 ~ 0xFF
0x00
138
31.11
Automatic reset item 2
X
0x00 ~ 0xFF
0x00
138
31.12
User reset item selection
X
0~29
0
138
31.13
Restart trial 1
X
0~10
0
138
31.14
Restart trial 2
X
0~10
0
138
31.15
Earth Fault
X
0.0 to 100.0 [%]
0.0: Disable
0.0 %
139
31.16
Supply phase loss
O
0 to 30 [Sec]
0: Disable
10 Sec
139
31.17
Stall function
X
0. No Operation
1. VFD overload
2. Over Voltage
3. VFD overload and Over Voltage
3
139
31.18
Stall current limit
X
20.0 to 200.0 [%]
150.0 %
139
31.19
Stall deceleration time
O
0.1 to 10.0 [Sec]
1.0 Sec
140
31.22
RS485 Modbus time out check
O
0. Always running
0
140
