8.1.11 Frequency reference
No.
Name
Change during
operation
Range
Default
Page
22.01
Frequency ref input (keypad)
O
0.00 to 400.0 [Hz]
0.00 Hz
114
22.03
Frequency ref 1 source
X
0. Not Selected
1. AI1 (O)
2. AI2 (OI)
3. Modbus
4. Field bus
5. PID
6. Keypad
7. UP / DOWN
1
114
22.04
Frequency ref 2 source
X
2
114
22.05
Frequency ref 1/ref 2
combination
X
0. '22,03'
1. '22,03' + '22.04'
2. '22,03' – '22.04'
3. '22,03' x '22.04'
4. MIN ('22,03' , '22.04' )
5. MAX ('22,03' , '22.04' )
0
115
22.06
Frequency ref 1/ref 2
selection
X
0. '22.05' setting value
1. '22,04' setting value
2. DI1
3. DI2
4. DI3
5. DI4
6. DI5
7. DI6
8. DI7
9. DI8
0
115
22.07
Constant frequency source 1
X
0. Not selected
1. Selected
2. DI1
3. DI2
4. DI3
5. DI4
6. DI5
7. DI6
8. DI7
9. DI8
0
116
22.08
Constant frequency source 2
X
0
117
22.09
Constant frequency source 3
X
0
117
22.10
Constant frequency 1
X
0.00 to 400.0 [Hz]
5.00 Hz
117
22.11
Constant frequency 2
X
0.00 to 400.0 [Hz]
10.00 Hz
117
22.12
Constant frequency 3
X
0.00 to 400.0 [Hz]
20.00 Hz
117
22.13
Constant frequency 4
X
0.00 to 400.0 [Hz]
30.00 Hz
117
22.14
Constant frequency 5
X
0.00 to 400.0 [Hz]
40.00 Hz
117
22.15
Constant frequency 6
X
0.00 to 400.0 [Hz]
50.00 Hz
117
22.16
Constant frequency 7
X
0.00 to 400.0 [Hz]
60.00 Hz
117
22.17
Jogging 1 ref
X
0.00 to 400.0 [Hz]
0.00 Hz
118
22.18
Jogging 2 ref
X
0.00 to 400.0 [Hz]
0.00 Hz
118
