Adtech iMASTER – A1 Series - VFD Running Status; Frequency Reference Indication; Trip Information

A1-User’s Manual
５８
8.1.1 VFD running status
No.
Name
Range
Page
01.01
Output frequency monitor
0.00 to 400.0 [Hz]
80
01.02
Motor RPM monitor
0 to 60000 [rpm]
80
01.03
Encoder Speed monitor
0 to 60000 [rpm]
80
01.04
Rotation direction monitor
STP / FWD / REV
80
01.05
Output current monitor
0.0 to 2000 [A]
80
01.07
DC voltage monitor
0 to 1000 [V]
80
01.08
Output voltage monitor
0 to 1000 [V]
81
01.09
Output power monitor
0.0 to 1000 [kW]
81
8.1.2 Frequency reference indication
No.
Name
Range
Page
02.01
Final frequency reference monitor
0.00 to 400.0 [Hz]
82
02.02
Modbus frequency reference monitor
0.00 to 400.0 [Hz]
82
02.03
Fieldbus frequency reference monitor
0.00 to 400.0 [Hz]
82
8.1.3 Trip information
No.
Name
Range
Page
03.01
Current trip, Source of Trip
-
83
03.02
Current trip, Frequency at Trip
0.00 to 400.0 [Hz]
83
03.03
Current trip, Current at Trip
0.0 to 2000 [A]
83
03.04
Current trip, Vdc at Trip
0 to 1000 [V]
83
03.05
Current trip, Running Status at Trip
STP, ACC, STD, DEC
83
03.06
Current trip, DI Status at Trip
0x00 to 0xFF
83
03.07
Current trip, DO Status at Trip
0x00 to 0xFF
83
03.08
Current trip, IGBT Temperature at Trip
0.0 to 160.0 [°C]
83
03.09
Current trip, Occurred time (Year)
2000 to 2099 [Year]
84
03.10
Current trip, Occurred time (Month, Day)
101 to 1231 [Month, Day]
84
03.11
Current trip, Occurred time (Hour, Minute)
0 to 2359 [Hour, Minute]
84
03.12
Current trip, Occurred time (Second)
0 to 59 [Sec]
84
03.13
Trip monitor 1, Source of Trip
-
84
03.14
Trip monitor 1, Frequency at Trip
0.00 to 400.0 [Hz]
84
03.15
Trip monitor 1, Current at Trip
0.0 to 2000 [A]
84
03.16
Trip monitor 1, Vdc at Trip
0 to 1000 [V]
84
03.17
Trip monitor 1, Running Status at Trip
STP, ACC, STD, DEC
84
03.18
Trip monitor 1, DI Status at Trip
0x00 to 0xFF
84
03.19
Trip monitor 1, DO Status at Trip
0x00 to 0xFF
84
03.20
Trip monitor 1, IGBT Temperature at Trip
0.0 to 160.0 [°C]
84
03.21
Trip monitor 1, Occurred time (Year)
2000 to 2099 [Year]
84
03.22
Trip monitor 1, Occurred time (Month, Day)
101 to 1231 [Month, Day]
84
03.23
Trip monitor 1, Occurred time (Hour, Minute)
0 to 2359 [Hour, Minute]
84
03.24
Trip monitor 1, Occurred time (Second)
0 to 59 [Sec]
84
03.25
Trip monitor 2, Source of Trip
-
84
03.26
Trip monitor 2, Frequency at Trip
0.00 to 400.0 [Hz]
84
03.27
Trip monitor 2, Current at Trip
0.0 to 2000 [A]
84
03.28
Trip monitor 2, Vdc at Trip
0 to 1000 [V]
84
03.29
Trip monitor 2, Running Status at Trip
STP, ACC, STD, DEC
84
03.30
Trip monitor 2, DI Status at Trip
0x00 to 0xFF
84
