8.2 Parameter detail
8.2.1 VFD running status
 01.01 Output frequency monitor
Range: 0.00 ~ 400.0 Hz
Real time display of output frequency of the VFD
It displays in 0.01 unit if the frequency is under 100Hz
It displays in 0.1 unit if the frequency is above 100Hz
 01.02 Motor RPM monitor
Range: 0 ~ 60000 RPM
below determined by equation:
120 X '01.01' (Output frequency) X '42.02' (RPM display scale factor ) / '99.07' (Motor
Pole setting)
ex1) '01.01' = 60Hz, '42.02' =100, '99,07' = 4 : '01.02' = 1800rpm
ex2) '01.01' = 60Hz, '42.02' =50, '99,07' = 4 : '01.02' = 900rpm
 01.03 Encoder Speed monitor
Range: 0 ~ 60000 RPM
Displays the RPM received from the encoder.
 01.04 Rotation direction monitor
STP: Stop
FWD: Forward Run
REV: Reverse Run
Real time display of rotation of the VFD
 01.05 Output current monitor
Range: 0.0 ~ 2000 A
Real time display of output current of the VFD
It displays in 0.1 unit if the output current is under 1000A
It displays in 1 unit if the output current is above 1000A
 01.07 DC voltage monitor
Range: 0 ~ 1000 V
Real time voltage on DC bus
