8.1.14 Over voltage suppression
No.
Name
Change during
operation
Range
Default
Page
25.01
OVS selection
O
0: Disable
1: Enable
0
129
25.02
Maximum OVS output
frequency
O
0.0 to 300.0 [Hz]
20.00 Hz
129
25.03
OVS P gain
O
0 to 10000
1000
129
25.04
OVS I gain
O
0 to 10000 [Sec]
100 Sec
129
25.05
OVS D gain
O
0 to 10000 [Sec]
0 Sec
130
25.06
q-Current reference
O
-100.0 to 100.0
0.0
130
25.07
Filter bandwidth
O
0.0 to 1000 [ms]
1 ms
130
25.08
Limit time
O
0.0 to 100 [Sec]
0.5 Sec
131
25.09
OVS Vdc Level (HF)
O
0 to 2000 [V]
700 V
131
25.10
OVS Vdc Level (LF)
O
0 to 1000 [V]
350 V
131
8.1.15 KEB
No.
Name
Change during
operation
Range
Default
Page
26.01
KEB selection
X
0: Disable
1: Enable
0
133
26.02
KEB gain
X
1 to 1000
100
133
8.1.16 DWELL
No.
Name
Change during
operation
Range
Default
Page
27.01
DWELL reference at start
X
0.00 to 400.0 [Hz]
0.00 Hz
134
27.02
DWELL time at start
X
0.0 to 10.0 [Sec]
0.0 Sec
134
27.03
DWELL reference at stop
X
0.00 to 400.0 [Hz]
0.00 Hz
134
27.04
DWELL time at stop
X
0.0 to 10.0 [Sec]
0.0 Sec
134
8.1.17 Frequency limits
No.
Name
Change during
operation
Range
Default
Page
30.01
Maximum frequency
O
0.00 to 400.0 [Hz]
60.00 Hz
135
30.02
Minimum frequency
O
0.00 to 400.0 [Hz]
0.00 Hz
135
