Adtech iMASTER – A1 Series - Trip Information

A1-User’s Manual
８４
8.2.3 Trip information
When fault occurs, the VFD automatically displays this parameter
Additional information of the fault can be accessed by using up arrow key
 03.01 Current trip, Source of trip
Displays source of trip
 03.02 Current trip, Frequency at trip
Displays frequency at trip
 03.03 Current trip, Current at trip
Displays current at trip
 03.04 Current trip, Vdc at trip
Displays Vdc at trip
 03.05 Current trip, Running Status at trip
Displays VFD status at trip
 03.06 Current trip, DI Status at trip
Displays digital input status at trip
refer to '10.01' (DI status)
 03.07 Current trip, DO Status at trip
Displays digital output status at trip
refer to '10.22' (DO status)
 03.08 Current trip, IGBT Temperature at trip
Displays IGBT temperature at trip
