2. Specifications
2.1 Specifications
2.1.1 200V class (032A ~ 310A)
Model A1-xxxA
(Note1)
-2
032
045
064
076
090
114
Motor Applied [kW]
(Note2)
HD
5.5
7.5
11
15
18.5
22
ND
7.5
11
15
18.5
22
30
Rated
Output
Rated Output
(Note3)
Current [A]
HD
24
32
45
64
76
90
ND
32
45
64
76
90
114
Rated
Capacity [kVA]
HD
200V
8
11
16
22
26
31
240V
10
13
19
27
32
37
ND
200V
11
16
22
26
31
39
240V
13
19
27
32
37
47
Output Frequency [Hz]
0~400Hz
(Note4)
Output Voltage [V]
3 Phase 200~240V
(Note5)
Rated
Input
Available Voltage [V]
3 phase 200~240V (± 10%)
Input Frequency [Hz]
50/ 60Hz (± 5%)
Rated Input Current [A]
HD
23
32
45
64
77
92
ND
31
45
64
77
91
116
Power loss [kW]
HD
0.15
0.21
0.31
0.42
0.52
0.62
ND
0.21
0.31
0.42
0.52
0.62
0.84
EMC Filter
Built-in 61800-3 C3
Model A1-xxxA
(Note1)
-2
140
170
205
261
310
-
Motor Applied [kW]
(Note2)
HD
30
37
45
55
75
-
ND
37
45
55
75
90
-
Rated
Output
Rated Output
(Note3)
Current [A]
HD
114
140
170
211
261
-
ND
140
170
205
261
310
-
Rated
Capacity [kVA]
HD
200V
39
48
59
73
90
-
240V
47
58
71
88
108
-
ND
200V
48
59
71
90
107
-
240V
58
71
85
108
129
-
Output Frequency [Hz]
0~400Hz
(Note4)
Output Voltage [V]
3 Phase 200~240V
(Note5)
Rated
Input
Available Voltage [V]
3 phase 200~240V (± 10%)
Input Frequency [Hz]
50/ 60Hz (± 5%)
Rated Input Current [A]
HD
102.9
126.9
154.4
187.7
257.3
-
ND
126.9
154.4
188.7
257.3
308.8
-
Power loss [kW]
HD
0.60
0.74
0.90
1.10
1.50
-
ND
0.74
0.90
1.10
1.50
1.80
-
EMC Filter
Built-in 61800-3 C3
