Adtech iMASTER – A1 Series - Standard AI (O, OI)

A1-User’s Manual
６２
No.
Name
Change during
operation
Range
Default
Page
10.32
Alarm Relay
(AL0-AL1-AL2) source
X
0. Run
1. FA1
2. FA2
3. OL
4. OD
5. AL
5
94
10.33
Alarm Relay
(AL0-AL1-AL2)
ON delay time
O
0.0 to 3000 [Sec]
0.0 Sec
94
10.34
Alarm Relay
(AL0-AL1-AL2)
OFF delay time
O
0.0 to 3000 [Sec]
0.0 Sec
94
10.35
VFD Overload warning level
X
10.0 to 200.0 [%]
100.0 %
95
10.36
FA2 reference at acceleration
X
'10.37' to '30.01' [Hz]
0.00 Hz
95
10.37
FA2 reference at deceleration
X
0.00 to '10.36' [Hz]
0.00 Hz
95
10.38
PID Error Tolerance
X
0.0 to 100.0 [%]
100.0 %
95
8.1.7 Standard AI (O, OI)
No.
Name
Change during
operation
Range
Default
Page
11.01
AI (O, OI) forced selection
X
0x00 to 0xFF
0x00
96
11.02
AI1 (O) actual value
-
0.0 to 100.0 [%]
-
96
11.03
AI1 (O) scaled value
-
0.00 to 400.0 [Hz] - Frequency
0.0 to 100.0 [%] - PID
-
96
11.04
AI1 (O) forced value
O
0.0 to 100.0 [%]
0.00 %
96
11.05
AI1 (O) filter time
O
0 to 30000 [ms]
100 ms
97
11.06
AI1 (O) source min
X
0.0 to 100.0 [%]
0.00 %
97
11.07
AI1 (O) source max
X
0.0 to 100.0 [%]
100.0 %
97
11.08
AI1 (O) scaled at AI1 min
X
0.00 to 400.0 [Hz] - Frequency
0.0 to 100.0 [%] - PID
0.00 Hz
97
11.09
AI1 (O) scaled at AI1 max
X
0.00 to 400.0 [Hz] - Frequency
0.0 to 100.0 [%] - PID
60.00 Hz
98
11.10
AI2 (OI) actual value
-
0.0 to 100.0 [%]
-
98
11.11
AI2 (OI) scaled value
-
0.0 to 100.0 [%]
-
98
11.12
AI2 (OI) forced value
O
0.0 to 100.0 [%]
0.00 %
99
11.13
AI2 (OI) filter time
O
0 to 30000 [ms]
100 ms
99
11.14
AI2 (OI) source min
X
0.0 to 100.0 [%]
0.00 %
99
11.15
AI2 (OI) source max
X
0.0 to 100.0 [%]
100.0 %
99
11.16
AI2 (OI) scaled at AI2 min
X
0.00 to 400.0 [Hz] - Frequency
0.0 to 100.0 [%] - PID
0.00 Hz
100
11.17
AI2 (OI) scaled at AI2 max
X
0.00 to 400.0 [Hz] - Frequency
0.0 to 100.0 [%] - PID
60.00 Hz
100
