8.2.8 Standard AO (FM, AMI)
 12.01 AO (FM, AMI) forced selection
Range: 0x00 ~ 0xFF
Initial value: 0x00
Example Data: 0000000000000010
Meaning: R01, AO2 (AMI) ON, AO1 (FM) OFF
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
It displays when extension I/O card is connected
AO2
(AMI)
AO1
(FM)
The statuses of the analog input can be overridden for example testing purposes
A bit in parameters '12.04' (AO1 forced value) and '12.12' (AO2 forced value) are provided
for each analog input and its value is applied whenever the corresponding bit in this
parameter is 1
 12.02 AO1 (FM) actual value
Range: 0.00 ~ 100.0 % in 0.01 %
Displays the value of AO1 (FM) in V
 12.03 AO1 (FM) source
0: Out Frequency ----- Initial value
1: Out Ampere
2: Out Voltage
3: Out Power
4: Out torque
5: Modbus communication
6: DC link Voltage
Program what output performance to be monitored from following selections
 Set 0: Output Frequency
The highest analog output value is the maximum frequency value. The indicator
accuracy after the adjustment is about +/- 5%.
 Set 1: Output Current
The highest analog value is the 200% of rated VFD current. The indicator accuracy after
the adjustment is about +/- 10%.
 Set 2: Output Voltage
The highest analog value is the 100% of rated VFD voltage out. The indicator accuracy
after the adjustment is about +/- 10%.
