9.2 Trouble Shooting
9.2.1 Trip monitor display
Display the trip source and operation status when occurred the trip
Display until the previous five trip event in '03.13' ~ '03.72'
Each trip contents are displayed below flow
1) Source of trip
2) Frequency at trip
3) Current at trip
4) Vdc at trip
5) Running status at trip
6) DI status at trip
7) DO status at trip
8) Temperature at trip
9) Torque at trip
Trip event
Contents
Description
Trip monitor 1
'03.13' ~ '03.24'
Source, Frequency, Current, Vdc, Running status,
DI status, DO status, Temperature, Torque
Trip monitor 2
'03.25' ~ '03.36'
Same with the Trip monitor 1
Trip monitor 3
'03.37' ~ '03.48'
Same with the Trip monitor 1
Trip monitor 4
'03.49' ~ '03.60'
Same with the Trip monitor 1
Trip monitor 5
'03.61' ~ '03.72'
Same with the Trip monitor 1
Trip counter
'03.73'
Displays the trip accumulation count
