A1-User’s Manual
１４０
 31.10 Automatic reset item 1
 Range: 0x00 ~0xFF
 Initial value: 0x00
Selects faults that are automatically reset the parameter is a 16-bit word with each bit
corresponding to a fault type. Whenever a bit is set to 1, the corresponding fault is
automatically reset. The bits of this binary number correspond to the following faults
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
EE 5
EE 4
EE 3
EE 2
EE 1
User
-
-
-
-
-
-
Sc
Lv
ov
oC
 31.11 Automatic reset item 2
See the parameter '31.10' (Automatic reset item 1)
 31.12 User reset item selection
 Range: 0~32
 Initial value: 0
Defines the fault that can be automatically reset using parameter '31.10' (Automatic reset
item 1) or '31.10' (Automatic reset item 1), bit 10
Value
Type of Trip
Value
Type of Trip
0
-
16
-
1
oC (Over Current)
17
SAFE (Safety Fault)
2
ov (Over Voltage)
18
-
3
Lv (low Voltage)
19
ovSF (OVS Fail)
4
Sc (Short circuit)
20
-
5
-
21
-
6
ot (Over Temperature)
22
EE2 (External Emergency 2)
7
EtH(Motor Over Load)
23
EE3 (External Emergency 3)
8
EE1 (External Emergency 1)
24
EE4 (External Emergency 4)
9
E2PE (EEPROM Error)
25
EE5 (External Emergency 5)
10
CE (Communication Error)
26
-
11
-
27
FF (Fan Fault)
12
GF (Ground Fault)
28
Profibus-DP Trip
13
-
29
Device-Net trip
14
Iolt (VFD Over Load)
30
System OL trip
15
PF (Input Phase Loss Fault)
31
System UL trip
32
Day of use Limited Trip
 31.13 Restart trial 1
 Range: 0 ~10 in 1
 Initial value: 0
Defines the number of automatic fault resets at '31.10' (Automatic reset item 1)
 31.14 Restart trial 2
 Range: 0 ~10 in 1
 Initial value: 0
