A1-User’s Manual
１６３
Ex2) Acceleration time 1 (Parameter: 0x1704, Data: 0x0064)
Command
Parameter
Communication Data
Data
(Conversion hexa to decimal)
0x0006
0x1704
100(10.0sec => 100)
1
st
byte : 0x00
2
nd
byte : 0x64
Ex3) Run command (Parameter: 0x0002, Data: FWD)
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Reserved
RST
REV
FWD
Command
Parameter
Data
0x0006
0x0002
0x0001(FWD: 0x0001, REV: 0x0002, RST: 0x0004)
Trip information items
Value
Type of Trip
Value
Type of Trip
0
-
16
-
1
oC (Over Current)
17
SAFE (Safety Fault)
2
ov (Over Voltage)
18
-
3
Lv (low Voltage)
19
ovSF (OVS Fail)
4
Sc (Short circuit)
20
-
5
-
21
-
6
ot (Over Temperature)
22
EE2 (External Emergency 2)
7
EtH(Motor Over Load)
23
EE3 (External Emergency 3)
8
EE1 (External Emergency 1)
24
EE4 (External Emergency 4)
9
E2PE (EEPROM Error)
25
EE5 (External Emergency 5)
10
CE (Communication Error)
26
-
11
-
27
FF (Fan Fault)
12
GF (Ground Fault)
28
Profibus-DP Trip
13
-
29
Device-Net trip
14
Iolt (VFD Over Load)
30
System OL trip
15
PF (Input Phase Loss Fault)
31
System UL trip
32
Day of use Limited Trip
Trip information Parameter
Current
Trip
Previous
Trip1
Previous
Trip2
Previous
Trip3
Previous
Trip4
Previous
Trip5
Trip
count
1
st
byte
0x03
0x03
0x03
0x03
0x03
0x03
0x03
2
nd
byte
0x01
0x0D
0x19
0x25
0x31
0x3D
0x49
