customercare@aem-test.com | Version # : 2.2

TestPro CV100

User Manual

•

Select[Connector:GenericCat6A].

Select[GenericShielded].

Select[CAT6A].

Follow a similar process for choosing connectors:

ii: Add New Cable

There are cases that the cable being used to test is not yet

available in AEM TestPro cable database. In this case, users

can add a cable in the database to be used for testing &

certication.ToaddnewcablepartnumbertotheTestPro’s

database, contact AEM support @ customercare@aem-

test.com

•

Select[Cable:GenericCat6A].

Select[Add].

Name – name or part number of the new cable

Manufacturer – manufacturer name of the cable.

The new cable will be saved under this name in the

database.

Grade – cable grade (CAT3 to CAT8)

Type – UTP, STP, FTP, etc.Impedance: 100 Ohms

Pair Combination: all pairs enabled by default

Whenalleldsarecompleted,select[Add]tosavethe

new cable in the database.

•

f.LabelSchemes

Labeling allows user to identify the associated physical

locations (i.e., building, room, cabinet, rack ,port, etc.). These

labels will be used to save the test results to the TestPro.

i: Create New Label

•

Select[LabelScheme:SimpleLabel].Apreviewofthe

simple labels will be displayed.

Select[Edit]toviewortoaddtothelistoflabelschemes.

Select[Add]tocreateanewlabel.

•

Key in the desired label name as well as the descriptions

for[Start]and[End].

Select[Add]tonishcreatingthelabel.

Select[Yes]tothedialogboxconrmingthenewlabel

as the current label scheme.

•

Note: The text in Start label should be lower than the

End label i.e., 01 against 10. The text should match as

well i.e., rst 4 characters are alphabet the end label

should also start with alphabet.

Refer this section to s. USB ii: Import Label List

ii:ImportCustomLabel

g.Operator

AddingOperator name ina projectand proleisanother

important step in documenting the test result. When test

reports are generated it includes the operator name to

identifywhoconductedthecerticationtest.

Select[Operator:Default].Apreviewoftheoperators

saved in Testpro will be displayed.

Select[Add]toaddnewoperator.

Keyintheoperator’snameorinitialsandselect[Ok].

•
