TestPro CV100
User Manual
h. Result AutoSave
[ResultAutoSave],whensetto[ForAllInstancesorOnlywith
PassResult]willsavethetestresultsaccordingtothenext
available label name.
Select[Certication].
Select[ResultAutoSave].
Select [For All Instances, Only with Pass Result or Don’t
AutoSave]
•
•
•
For All Instances – TestPro will save all test result
Only with Pass Result – TestPro will save only when the test
result is a Pass
Don’t AutoSave – no AutoSave of any test result
i. Auto Start
Select[Certication].
Select[AutoStart].
Select[Yes]or[No].
•
•
•
If[Yes],TestProwillautomaticallystarttheAutotestwhenthe
cable under test is connected to the device port.
When [Only for Bidirectional Test After Fiber Swapping] is
enabled, the Autotest will continue after successfully swapping
thebercableduringadual-endedbi-directionaltest.
When [Do Autotest if Wiremap Failed] is enabled, the
Autotest will perform a Autotest when any of the 4 pairs
fails the Wiremap.
j. Long Cable
Long Cable supports the testing of cables between 500 and
1000 meters.
Select[Certication].
Enable[LongCable].
•
•
Note that the long cable options in the main and remote
devices should be enabled. This feature is automatically
disabled when devices are restarted.
k.LicenseDetails
Customers who purchased the K05 and K30 kits will need a
certicationLicensetosavethetestresultwhenusingthe
AD-CAT6A-CH adapter.
UserswithK05andK30kitswhopurchasedtheberkitswill
notrequirealicensetoperformbercerticationtestasthe
licenseisincludedwiththepurchaseoftheberadapter.
