AEQ FORUM
Digital audio mixer for broadcast applications
79
4.3.2.5. Configuration of “Multiplex“ programmable keys.
Programmable keys that are set to “Multiplex” enables you to make a quick management of
signal routing toward a “MPX” type internal summing bus (these buses are typically used for
sending to codecs, hybrids or other auxiliary destinations). A key set to this function is assigned
with a dedicated icon.
The lower part of the “Programmable Keys” submenu will show the associated options for
“Multiplex” type keys, when this configuration mode is selected. In order to be able to configure
the programmable key (or edit a previously created configuration), you have to press the “Edit
Configuration” button, to active and allows you to assign to that key one of the 8 available
“MPX” buses:
2
