AEQ FORUM
Digital audio mixer for broadcast applications
89
4.3.5. “SnapShot Configuration” submenu.
“SnapShot Configuration” submenu is accessed, from the drop-down menu “Programmable
Configuration”, by clicking on the icon:
“SnapShot Configuration” submenu allows you to manage the different configurations memories
stored in AEQ FORUM and available to operators through the internal menu of the main screen
of the Control and Monitoring section of the unit. Please refer to section 3.3 of this manual.
The main screen of this submenu is presented as a list of all the snapshots stored (there are up
to 7 available snapshots), ordered by their “Id” and with a “Label” or name as identifier.
The advanced configuration menu of each one of the snapshots is accessed by clicking “Click
to [CONFIG]” and then clicking again on the
button that will appear. The screen you access
to looks as follows:
