AGFA CR 10-X Service Manual

DD+DIS155
.11E
Functional Description
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library. Any printed copy of this document is uncontrolled.
5.1.2 Taking the Image Plate out of the Cassette
517502ec.cdr
Slow Scan Drum (magnetic)
IP Drawer
Light Sensor
Flag
IP Drawer Module
Image Plate
Magnets
IP Drawer Module Roller (magnetic)
Home Position
Docking Position
Figure 13
Edition 1, Revision 1 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 2 / Page 16 of 19
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
