AGFA CR 10-X Service Manual

DD+DIS155
.11E
About this Manual
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library Any printed copy of this document is uncontrolled.
1 About this Manual
1.1 Scope of this Manual
This Service Manual describes the service activity related items for following
products:
 Digitizer CR 10-X, Type 5151, subtype 100
 CR Reader, Type 5151, subtype 110
 Digitizer CR 12-X, Type 5151, subtype 200
 CR Reader, Type 5151, subtype 210
 Cassette Set CR MD 1.0 General (Cassette and image plate), 35x43 cm,
Type 5188/100
For differences of the digitizers refer to chapter 11, Installation Planning.
This Service Manual is available on the Agfa HealthCare Library.
Refer to: Computed Radiography => CR Digitizers => CR 10-X
1.2 System Overview
The digitizer is part of a CR system,
comprising:
 Digitizer
 Cassette(s) with image plate(s)
 NX Workstation or other medical
workstation.
515100ab.cdr
Digitizer
Cassette
NX Workstation
Figure 1
Edition 1, Revision 1 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 0 / Page 6 of 7
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
