8 Specifications
8.1 Type Overview
Type ABC Code Serial Number
5151 / 100 5R3EQ 1.001 to 19.999
5151 / 110 5W784 20.001 to 29.999
5151 / 200 5W8AB 30.001 to 39.999
5151 / 210 5W8DH 40.001 to 49.999
8.2 Functional Data
Cycle time [seconds] @ scan resolution*
Type 5151/100 and 110:
106 @ 100 µm
Type 5151/200 and 210:
90 @ 100 µm
72 @ 150 µm
60 @ 200 µm
Bits per pixel / number of grey steps
16 / 65535
Image Buffer [MB]
128
* Scan resolution for type 5151/200 and 210 can be selected by the user before scanning at the NX
workstation.
8.3 Electrical Data of Digitizer
Rated voltage [~V]
100 – 240 AC (autosensing)
Frequency [Hz]
50/60
Power consumption type
5151 / 100 and 110 [W]
Standby:
Average during scan:
41
65
Power consumption type
5151 / 200 and 210 [W]
Standby:
Average during scan:
22
78
Fuse [A]
Europe max. 16
USA max. 15
