AGFA CR 10-X Service Manual

DD+DIS155
.11E
Repair and Service
Adjustments and Calibrations
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library. Any printed copy of this document is uncontrolled.
(10) Remove the cassette from the digitizer.
(11) Select menu <Logout> and follow the logout wizard.
(12) Close the browser.
2.4 Verifying a successful Shading Calibration
Verification
(1) Expose a flatfield. Use the same exposure parameters like for the
shading calibration.
(2) Identify and scan the image. Use exam type: System diagnosis 
Flatfield
IMPORTANT:
By selection of examination type System diagnosis  Flatfield the correct
settings for image processing of the flatfield are used.
Any other examination type may give a result which cannot be used to evaluate the
flatfield image.
(3) Visually check the image for homogeneity in IP run direction and vertical to the
IP run direction.
Evaluation:
 If the scanned flatfield image does not show any lines or stripes or large area
inhomogeneities no further action is required.
 If there are unacceptable effects, see service manual chapter 3.3,
Troubleshooting.
Result
The shading calibration is finished.
Edition 1, Revision 1 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 3.6 / Page 9 of 10
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
