AGFA CR 10-X Service Manual

DD+DIS155
.11E
Repair and Service
Troubleshooting
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library. Any printed copy of this document is uncontrolled.
Edition 1, Revision 2 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 3.3 / 18 of 46
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
CODE Message
ARC1200
IP-transport error.
Meaning: Movement of the Handling has not finished successfully.
The control reached an unexpected situation.
Check the description of the Error Code for more specific information.
Reason 1: Error during operation.
Cure 1: Restart digitizer to perform the startup selftest procedure.
Watch out for messages, e.g. if an IP has to be removed.
Reason 2: Software problem.
Cure 2: Load new Software.
Reason 3: 'Power Board' defective.
Cure 3: Check 'Power Board' and replace if defective.
ARC1201
No IP present at IP Sensor at the end of the tray.
Meaning: Transport of the IP to the 'IP Detection Light Sensor' not successful.
At the IP Detection Light Sensor no IP is detected after the scan movement.
Reason 1: Transport of the IP not successful.
Cure 1: Restart Digitizer.
Reason 2: IP has jammed.
Cure 2: Open Digitizer and remove jammed IP.
ARC1202
Unexpected IP found at the beginning of a new cycle.
IP present at IP Detection Light Sensor.
Meaning: At the last cycle the expected transport of the IP into the Cassette
was not successful.
At the 'IP Detection Light Sensor' an IP is detected at the start movement of the
new cycle.
Reason 1: Handling of the IP not successful.
Cure 1: Restart Digitizer.
Reason 2: IP has jammed.
Cure 2: Open Digitizer and remove jammed IP.
