AGFA CR 10-X Service Manual

DD+DIS155
.11E
Functional Description
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library. Any printed copy of this document is uncontrolled.
Edition 1, Revision 1 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 2 / Page 13 of 19
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
# Comment
1 Approx. 1 second after switch on the status LED starts red blinking.
2 After boot-up of the PMI board (approx. 17 seconds after switch on), until
sending the self-test signal (approx. 40 seconds after switch on), the digitizer
performs following actions:
 The internal logging and error messages are loaded.
 The data in the E-labels are compared with the E-label data on the USB
flash drive.
The status LED stays red blinking. No audible actions. No message in the
Error Viewer.
3 Send self test signal to all SW modules means: Check whether all consumers
are connected. Click sounds of motors are audible. The galvo starts up.
4 When the self test starts, message “Digitizer start-up” is displayed in the Error
Viewer.
This message is generated by the digitizer and will not be displayed however,
if the error viewer is not started-up yet. This is the case for example if digitizer
and workstation are switched on simultaneously.
5 During the IP Clean-up cycle, the drawer motors is briefly audible.
6 If the NX viewer is not running following message appears in the Error Viewer:
“Image processing software is not available. Restart the image processing
software”. The check whether the NX application is running is repeated each
three seconds, even after successful connection.
Exception: After a scan cycle, when the cassette is waiting to be removed by
the customer, the digitizer does not check, whether the NX application is
running.
