1260 Infinity Binary Pump User Manual 139
Test Functions and Calibration
8
Leak Rate Test
curve segment corresponds to the flow and leak rate at that time and the
leak rate is measured.
Subsequently, piston 2 is moved to its rear position, then piston 2 delivers
and the measurement is done as described for piston 1.
For a binary pump (G1312B/C, K1312B), the test is run for both pump
heads for channels A and B.
Running the Test
Running the test from the Agilent Lab Advisor
1 Select the Leak Rate Test from the Test Selection menu.
2 Start the test and follow the instructions.
Parts required p/n Description
01080-83202 Blank nut
Make sure to release the pressure by slowly opening the purge valve when the test has
finished.
