1260 Infinity Binary Pump User Manual 159
Maintenance
10
Maintenance of a Pump Head without Seal Wash
Maintenance of a Pump Head without Seal Wash
When In case of maintenance or pump head internal leaks
Tools required p/n Description
8710-0510 Wrench open 1/4 — 5/16 inch
8710-2411 Hex key 3 mm12 cm long
8710-2392 Hex key 4 mm15 cm long T-handle
01018-23702 Insert tool
Parts required # p/n Description
1 5063-6589 Piston seal PTFE, carbon filled, black (pack of 2), default
OR 1 0905-1420 PE seals (pack of 2)
1 5063-6586 Sapphire piston
Preparations Switch off the pump at the main power switch
Remove the front cover to have access to the pump heads
“Removing the Pump Head Assembly” on page 157
NOTE
Both pump head assemblies use the same internal components. In addition, pump head A
is fitted with the purge valve. The following procedure describes the removal and
disassembly of pump head A (left). For pump head B (right) proceed in the same way and
skip steps that deal with the purge valve.
