48 1260 Infinity Binary Pump User Manual
3 Installing the Pump
Flow Connections with Solvent Selection Valve
Flow Connections with Solvent Selection Valve
1 Remove the front cover by pressing the snap fasteners on both sides.
Figure 16 Removing the Front Cover
Parts required # p/n Description
1Other modules
1 G1311-68755 Accessory Kit
2 wrenches 1/4 - 5/16 inch for capillary connections
Preparations Pump is installed in the LC system
When opening capillary or tube fittings, solvents may leak out.
The handling of toxic and hazardous solvents and reagents can carry health risks.
➔ Observe appropriate safety procedures (for example, wear goggles, safety gloves
and protective clothing) as described in the material handling and safety data sheet
supplied by the solvent vendor, especially when toxic or hazardous solvents are
used.
