Setting the 8-bit Configuration Switch (without On-board) LAN
One start bit and one stop bit are always used (not selectable).
Per default, the module will turn into 19200 baud, 8 data bit with no
parity.
Tabl e 1 9 Baudrate Settings (without on-board LAN)
Switches Baud Rate Switches Baud Rate
345 345
0 0 0 9600 1 0 0 9600
001 1200 101 14400
010 2400 110 19200
011 4800 111 38400
Tabl e 2 0 Data Bit Settings (without on-board LAN)
Switch 6 Data Word Size
0 7 Bit Communication
1 8 Bit Communication
Tabl e 2 1 Parity Settings (without on-board LAN)
Switches Parity
78
0 0 No Parity
0 1 Odd Parity
1 1 Even Parity
