Agilent Technologies 1260 Infinity User Manual

40 1260 Infinity Binary Pump User Manual
3 Installing the Pump
Optimizing the Stack Configuration
Agilent 1260 Infinity Binary LC in Low Delay Volume Configuration
with Automated Column Regeneration and MS
This is the recommended setup to achieve minimum cycle time using MS
detection.
For a more detailed help on configuring your instrument, refer to the
Agilent 1260 Infinity Binary LC System User Guide.
Figure 11 Agilent 1260 Infinity Binary LC with Automated column regeneration and MS
detection in low delay volume configuration
Degasser
Reg. Pump
Pump
New LDV Heat - X
DAD or MWD 2 μl cell
0.12 mm ID cap.
TCC
ca. 320 mm x 0.12 mm
WPS
0.12 mm seat
Cooler f. WPS
650 mm x 0.17 mm
New LDV
post column cooler
SQ-MSD
