Agilent Technologies 35670A Service Guide

Single Ch Phase Accuracy
Measurement Lower Limit
(deg)
Upper Limit
(deg)
Measured Value
(deg)
Pass/Fail
Positive slope, Ch 1
−4
4
Positive slope, Ch 2
−4
4
Negative slope, Ch 1
−4
4
Negative slope, Ch 2
−4
4
External Trigger
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
8 V Pos
−10
10
8 V Neg
−10
10
−8 V Pos −10
10
−8 V Neg −10
10
Tach Function (option D01 only)
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
Trigger level +8V Pos
−10
10
Trigger level +8V Neg
−10
10
Trigger level −8V Pos −10
10
Trigger level −8V Neg −10
10
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Two Channel
12 of 14
