Agilent Technologies 35670A Service Guide

Input Resistance
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
27 dBVrms, Ch 1
−10
10
9 dBVrms, Ch 1
−10
10
−11 dBVrms, Ch 1 −10
10
27 dBVrms, Ch 2
−10
10
9 dBVrms, Ch 2
−10
10
−11 dBVrms, Ch 2 −10
10
ICP Supply
Measurement Lower Limit Upper Limit Measured Value Pass/Fail
Ch 1 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 2 Open Circuit Voltage
26 Vdc 32 Vdc Vdc
Ch 1 Current
2.75 mA 5.75 mA mA
Ch 2 Current
2.75 mA 5.75 mA mA
Source Amplitude Accuracy
Measurement Lower Limit
(%)
Upper Limit
(%)
Measured Value
(%)
Pass/Fail
1 kHz, 0.1 Vpk
−4
4
1 kHz, 3.0 Vpk
−4
4
1 kHz, 5.0 Vpk
−4
4
Source Output Resistance
Measurement Lower Limit Upper Limit
(ohm)
Measured Value
(ohm)
Pass/Fail
Resistance
5
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Performance Test Record - Two Channel
