Agilent Technologies 35670A Service Guide

Source DC Offset
Measurement Lower Limit
(mVdc)
Upper Limit
(mVdc)
Measured Value
(mVdc)
Pass/Fail
0 Vdc, 0 Vac(pk)
−15
15
−10 Vdc, 0 Vac(pk) −315
315
+10 Vdc, 0 Vac(pk)
−315
315
−5 Vdc, 5 Vac(pk) −315
315
+5 Vdc, 5 Vac(pk)
−315
315
0 Vdc, 5 Vac(pk)
−165
165
Source Flatness
Measurement Lower Limit
(dB)
Upper Limit
(dB)
Measured Value
(dB)
Pass/Fail
12.8 kHz
−1
1
25.6 kHz
−1
1
51.2 kHz
−1
1
102.4 kHz
−1
1
Source Distortion
Measurement Lower Limit Upper Limit
(dBc)
Measured Value
(dBc)
Pass/Fail
12.8 kHz
−60
51.2 kHz
−40
102.4 kHz
−40
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Verifying Specifications Agilent 35670A
Performance Test Record - Two Channel
14 of 14
