Agilent Technologies 35670A - To scale the Y-axis with Reference and Y Per Div softkeys

Two Ch, 44800 Hz Start, Ch 1
−80
Two Ch, 44800 Hz Start, Ch 2
−80
Two Ch, 46400 Hz Start, Ch 1
−80
Two Ch, 46400 Hz Start, Ch 2
−80
Two Ch, 48000 Hz Start, Ch 1
−80
Two Ch, 48000 Hz Start, Ch 2
−80
Two Ch, 49600 Hz Start, Ch 1
−80
Two Ch, 49600 Hz Start, Ch 2
−80
Amplitude Accuracy
Measurement Lower Limit
(dBVrms)
Upper Limit
(dBVrms)
Measured Value
(dBVrms)
Pass/Fail
−51 dBVrms, Ch 1 −51.15 −50.85
−51 dBVrms, Ch 2 −51.15 −50.85
−51 dBVrms, Ch 3 −51.15 −50.85
−51 dBVrms, Ch 4 −51.15 −50.85
−43 dBVrms, Ch 1 −43.15 −42.85
−43 dBVrms, Ch 2 −43.15 −42.85
−43 dBVrms, Ch 3 −43.15 −42.85
−43 dBVrms, Ch 4 −43.15 −42.85
−35 dBVrms, Ch 1 −35.15 −34.85
