Agilent Technologies 35670A Service Guide

Failing Performance Test Troubleshooting Guide
Failing Performance Test Probable Faulty Assembly
(in order of probabilty)
Adjustment Troubleshooting Test
Spurious signals
one channel
A1/A2 Input
A5 Analog
Input and ADC, page 4-51
Four channel, page 4-54
Spurious signals
channel 1 and 3 or
channel 2 and 4
A2 Input
Spurious signals
all channels
A5 Analog
mechanical
A6 Digital
ADC gain, offset, and
reference, page 5-7
Distortion, page 4-56
Noise
one channel
A1/A2 Input
A5 Analog
Input and ADC, page 4-51
Four channel, page 4-54
Noise
channel 1 and 3 or
channel 2 and 4
A2 Input
Noise
all channels
A5 Analog
mechanical
ADC gain, offset, and
reference, page 5-7
Distortion, page 4-56
Cross talk A1/A2 Input Distortion, page 4-56
ICP supply A1/A2 Input
Source dc offset A5 Analog
Source amplitude accuracy A5 Analog
Source flatness A5 Analog
Source distortion A5 Analog
Source output resistance A5 Analog
Troubleshooting the Analyzer Agilent 35670A
To troubleshoot performance test failures
4-44
