Remote Operation
Adjustments can be set up using the remote operation capability of the
Agilent 35670A analyzer. The following table lists the adjustments and corresponding
GPIB codes. See the Agilent 35670A GPIB Programmer’s Guide for general
information on remote operation.
Adjustment GPIB Code
Source DC Offset DIAG:SERV:ADJ:SOUR:OFFS
Source Filter DC Offset DIAG:SERV:ADJ:SOUR:FILT:OFF
S
ADC Second Pass Gain DIAG:SERV:ADJ:ADC:GAIN
ADC Offset DIAG:SERV:ADJ:ADC:OFFS
Channel 1 Offset DIAG:SERV:ADJ:OFFS1
Channel 2 Offset DIAG:SERV:ADJ:OFFS2
Channel 3 Offset (option AY6 only) DIAG:SERV:ADJ:OFFS3
Channel 4 Offset (option AY6 only) DIAG:SERV:ADJ:OFFS4
Channel 1 Common Mode Rejection DIAG:SERV:ADJ:CMRR1
Channel 2 Common Mode Rejection DIAG:SERV:ADJ:CMRR2
Channel 3 Common Mode Rejection (option AY6 only) DIAG:SERV:ADJ:CMRR3
Channel 4 Common Mode Rejection (option AY6 only) DIAG:SERV:ADJ:CMRR4
Channel 1 Flatness at 100 kHz DIAG:SERV:ADJ:FLAT1:FULL
Channel 1 Flatness at 50 kHz (option AY6 only) DIAG:SERV:ADJ:FLAT1:FULL
Channel 1 Flatness at 50 kHz DIAG:SERV:ADJ:FLAT1:CENT
Channel 1 Flatness at 25 kHz (option AY6 only) DIAG:SERV:ADJ:FLAT1:CENT
Channel 2 Flatness at 50 kHz DIAG:SERV:ADJ:FLAT2:FULL
Channel 2 Flatness at 25 kHz (option AY6 only) DIAG:SERV:ADJ:FLAT2:CENT
Channel 3 Flatness at 25 kHz (option AY6 only) DIAG:SERV:ADJ:FLAT3:FULL
Channel 4 Flatness at 25 kHz (option AY6 only) DIAG:SERV:ADJ:FLAT4:FULL
Preset SYST:PRES
Adjusting the Analyzer Agilent 35670A
5-4
