For the standard two channel analyzer, do the following to adjust filter flatness:
•
Set the power switch to on ( I ).
•
Press the following keys:
[
System Utility ]
[
MORE ]
[
SERVICE TESTS ]
[
ADJUSTMTS ]
[
CHANNEL 1 ADJUSTMNT ]
[
50 kHz ]
Wait for the analyzer to set up the adjustment. The analyzer is ready when
the adjustment message appears on the screen.
•
While monitoring the Yr: value, adjust A1 R115 for a marker value of
0 0.1 dB.
•
Press the [ 100 kHz FLATNESS ] softkey.
Wait for the analyzer to set up the adjustment. The analyzer is ready when
the adjustment message appears on the screen.
•
While monitoring the Yr: value, adjust A1 R235 for a marker value of
0 0.1 dB.
•
Press the following keys:
[
Rtn ]
[
CHANNEL 2 ADJUSTMNT ]
[
50 kHz FLATNESS ]
Wait for the analyzer to set up the adjustment. The analyzer is ready when
the adjustment message appears on the screen.
•
While monitoring the Yr: value, adjust A1 R615 for a marker value of
0 0.1 dB.
Adjusting the Analyzer Agilent 35670A
To adjust filter flatness
5-18
