Agilent Technologies 35670A Service Guide

A12 BNC
The A12 BNC assembly connects the BNC connectors on the two channel analyzer’s
front panel to their respective assembly. The Source BNC is connected to the A5
Analog assembly and the Channel 1 and Channel 2 BNCs are connected to the A1
Input assembly. In addition, this assembly provides RFI filtering for the Channel 1
and Channel 2 HIGH and LOW inputs.
Circuit Descriptions Agilent 35670A
A12 BNC
8-36
