A22 BNC
The A22 BNC assembly is only used in four-channel analyzers. The A22 BNC
assembly routes the signals connected to the Channel 1 BNC connector and Channel 3
BNC connector to the A2 Input assembly connected to J1 on the Motherboard. The
A22 BNC assembly also routes the signals connected to the Channel 2 BNC connector
and Channel 4 BNC connector to the A2 Input assembly connected to J2 on the
Motherboard. The signal connected to Channel 1 and Channel 2 should be between
0.097656 Hz to 51.2 kHz in two-channel mode and between 0.048828 Hz to 25.6 kHz
in four-channel mode. The signal connected to Channel 3 and Channel 4 should be
between 0.048828 Hz to 25.6 kHz. For all channels, the signal’s amplitude range must
be between +27 dBVrms and –51 dBVrms for full-scale measurements.
Voltages and Signals Agilent 35670A
A22 BNC
9-24
