[ Inst Mode ]
[ 2 CHANNEL ]
[ Input ]
[ CHANNEL 1 RANGE ]
1
[ dBVrms ]
[ CHANNEL 2 RANGE ]
1
[ dBVrms ]
[ Disp Format ]
[ UPPER/LOWER ]
[ System Utility ]
[ CALBRATIN ]
[ SAVE CH1 CAL TRACE ]
[ INTO D1 ]
[ SAVE CH2 CAL TRACE ]
[ INTO D2 ]
[ Meas Data ]
[ MORE ]
[ DATA REGISTER ]
[ D2 ]
[ Active Trace ]
[ D1 ]
[ Scale ]
[ Y PER DIV (DECADES) ]
1
[ ENTER ]
[ CENTER REFERENCE ]
0
[ ENTER ]
[ Active Trace ]
[ Y PER DIV (DECADES) ]
1
[ ENTER ]
[ CENTER REFERENCE ]
0
[ ENTER ]
Note
Display A shows the message
D1 CAL CHAN 1 and display B shows the message
D2 CAL CHAN 2.
The calibration correction curves should be contained within
±5 dB. The ±5 dB limit
applies to all ranges at full span.
Internal Test Descriptions Agilent 35670A
Calibration Routine Description
10-8
