Making Measurements — An Example
1 Turn on the power to the controller (PC).
2 Press the Start button, located at the bottom left of the task bar in the
Start menu window as shown in Figure 18.
3 Select Programs , then select the, for example, Agilent N1231B API program
from the pop- up menu.
The
Agilent N1231B API pop- up menu is displayed as shown in Figure 18.
Figure 18 Start/Programs pop-up menu
4 From the Agilent N 12 31B API pop- up menu, click on the  N1231B Monitor
icon to open the monitor application.
With no input signals connected to the Agilent N1225A board, the
Agilent N1225A Monitor screen should appear as shown in Figure 19.
NOTE
The PCI bus and slot number may differ from those shown in Figure19.
