Specifications 8
Agilent 5517B/BL/C/D/DL/FL User’s Guide 77
1
These values are based on use of current receivers and liner interferometers. Also, if the Agilent N1225A
Board is being used in the system, these velocity of motion values will decrease by 70
mm/s.
Vibration and Shock
Non-operating Vibration Random, 2.1 Grms, 5 to 500 Hz
Non-operating Shock Trapezoidal, 30 g, 20 ms
Physical Characteristics
Dimensions 5517B/C/D see Figure 26 on page 78; 5517BL/DL/FL see Figure 27 on page 79
Weight 3.4 Kilograms (7.5 pounds); 3.2 Kilograms (7 pounds) for 5517DL/FL
Clearance required for cabling: 10.16 cm (4 in) beyond back
Electrostatic Discharge
(ESD)
When the product is tested with 8kV air discharge or 4kV contact discharge in
accordance with IEC 61000-4-2, errors that will affect the measurement data may
occur during the disturbance. The axis board is designed to sense such incidents and
to stop further measurements. A reset via software must be performed on the axis
board to discard the erroneous data.
Additional Characteristics
Heat exhaust efficiency (typical,
depends on environmental
conditions)
5517BL
5517DL
5517FL
80% typical
80% typical
80% typical
Airflow conditions
(minimum, room temperature)
Enclosure
5517B/C/D
5517BL/DL/FL
4 m/s exiting head through 50 mm diameter duct
NEMA Type 12
Type IP10 per IEC 529
Tab le 1 5 Agilent Laser Head Specifications and Characteristics (continued)
