Chapter 2 Linear Measurements
Mounting and Aligning the Optics on the Target Machine
2-12 Measurements Reference Guide
5 Attach the interferometer to a retroreflector by following these steps:
Place one retroreflector on the interferometer so one of the arrows on the
interferometer’s label points toward the retroreflector (Figure 2-6).
Attach the two optics using the knurled screws included with the
retroreflector.
In the rest of this chapter, this assembly made up of the interferometer
and the retroreflector is referred to as the “interferometer assembly.”
