Agilent Technologies 6850 Series II User Manual

Automatic Liquid Sampler and Injector
The 6850 automatic liquid sampler
Released: March 2004 6850 Series II GC User Information page 234 of 256
4. Install one mounting screw, then rotate the turret. The outer edge should
remain level. Install the remaining screws.
5. Reinstall the ESD cap.
6. Align the turret. See “Align the turret” on page 234.
Align the turret
The alignment procedure makes sure that your 6850 ALS is ready for operation
using the installed turret.
Always perform an alignment after changing turret types (from the 2-mL vial
turret to the 4-mL vial turret, and vice-versa).
1. Remove all vials from the turret. Open the injector door and remove the
syringe.
2. Remove the needle support assembly. See “Replacing the needle support
assembly” on page 224.
3. Push the align button. The injector and turret will perform a series of
checks.
4. Loosen the screws in the clamps that hold the calibration probe to the
bottom of the turret and remove the probe. Do not remove the clamps.
Align button
