56 Agilent 8453 Dissolution Testing System Installing and Operating Manual
2Setting Up
Installing Your Multibath System
Selecting Voltage
This safety symbol next to the voltage selector on the rear panel of the
valve-pump controller (see Figure 20) indicates you should refer to the
following information.
Figure 20 Rear View of Valve-Pump Controller
Safety symbol
Voltage selector
Line power
socket
Serial number
(on base)
Check the line-voltage selector is set to the correct line voltage for operation from
your line-power supply, see Figure 10 and Tab le 11 for details.
Tab le 15 Voltage Selection
Power Supply Select
100–120 V AC 115 V AC
220–240 V AC 230 V AC
