72 Agilent 8453 Dissolution Testing System Installing and Operating Manual
3 Using the Peristaltic Pumps 1VS and 8VS
Installing Your Pump
Cassettes
The tubing-cassette has automatic pressure control, and slots for the tubing
with locating holes for the fixing-collars. See Figure 30.
Figure 29 Rear View of the Pump
Figure 30 Tubing-Cassette
Remote cable connector
Voltage selector
Line power socket
Fan outlet
Fixing collar Fixing collar
