8 Maintaining the MMI
Consumables and Parts for the Multimode Inlet
122 Maintaining Your GC
Consumables and Parts for the Multimode Inlet
See the Agilent catalog for consumables and supplies for a more complete listing, or visit the
Agilent Web site for the latest information (www.agilent.com/chem/supplies).
Table 21 Split, splitless, direct, and direct connect inlet liners
Mode Description Deactivated Part number
Split Low-pressure drop, glass wool, single taper, 870 µL Yes 5183-4647
Split Glass wool, 990 µL No 19251-60540
Split—Manual only Empty pin and cup, 800 µL No 18740-80190
Split—Manual only Packed pin and cup, 800 µL No 18740-60840
Splitless Single taper, glass wool, 900 µL Yes 5062-3587
Splitless Single taper, no glass wool, 900 µL Yes 5181-3316
Splitless Dual taper, no glass wool, 800 µL Yes 5181-3315
Splitless—Direct inject 2-mm id, quartz, 250 µL No 18740-80220
Splitless—Direct inject 2-mm id, 250 µL Yes 5181-8818
Direct inject —Headspace or purge
and trap
1.5-mm id, 140 µL No 18740-80200
Direct column connect Single taper, splitless 4-mm id Yes G1544-80730
Direct column connect Dual taper, splitless 4-mm id Yes G1544-80700
Table 22 Nuts, ferrules, and hardware for capillary columns
Column id (mm) Description Typical use Part number/quantity
.530 Ferrule, Vespel/graphite, 0.8-mm id 0.45-mm and 0.53-mm capillary columns 5062-3512 (10/pk)
Ferrule, graphite, 1.0-mm id 0.53-mm capillary columns 5080-8773 (10/pk)
Ferrule, graphite, 0.8-mm id 0.53-mm capillary columns 500-2118 (10/pk)
Column nut, finger-tight (for
0.53-mm columns)
Connect column to inlet or detector 5020-8293
.320 Ferrule, Vespel/graphite, 0.5-mm id 0.32-mm capillary columns 5062-3514 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for .100- to
.320-mm columns)
Connect column to inlet or detector 5020-8292
.250 Ferrule, Vespel/graphite, 0.4-mm id 0.1-mm, 0.2-mm, and 0.25-mm capillary
columns
5181-3323 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for .100- to
.320-mm columns)
Connect column to inlet or detector 5020-8292
