9 Maintaining the PTV Inlet
Consumables and Parts for the Programmable Temperature Vaporization Inlet
144 Maintaining Your GC
Consumables and Parts for the Programmable
Temperature Vaporization Inlet
See the Agilent catalog for consumables and supplies for a more complete listing, or visit the
Agilent Web site for the latest information (www.agilent.com/chem/supplies).
Table 24 PTV liners and ferrules
Description Part number
Single baffle, 2-mm id, 180-µL, deactivated, glass wool 5183-2038
Single baffle, 2-mm id, 200-µL, deactivated 5183-2036
Multi-baffle, 1.5-mm id, 150-µL, deactivated 5183-2037
Fritted glass, 1.5-mm id, 150-µL, deactivated 5183-2041
Graphpak 3D ferrules for liner 5182-9749 (5/pk)
Installation tool for 3D ferrules G2617-80540
Table 25 Other consumables and parts for the PTV inlet
Description Part number
Syringe, 5-µL, 23-gauge fixed-needle 9301-0892
Syringe, 10-µL, 23-gauge fixed-needle 9301-0713
Syringe, 50-µL, 23-gauge fixed-needle, for large volume injections 5183-0318
Syringe, 100-µL, 23-gauge fixed-needle, for large volume injections 5183-2058
Split vent trap PM kit, single cartridge 5188-6495
Septumless head
Septumless head G2617-60507
PTFE ferrules (needle seal) 5182-9748 (10/pk)
Septumless head rebuild kit (includes Viton seal, Kalrez seal, and pressure spring) 5182-9747
Carrier gas tube for septumless head G2617-80550
Ferrule, 1/16-inch PTFE, for septumless head carrier gas tube 0100-1375
Septum head
Merlin Microseal septum (high-pressure) 5182-3444
11-mm septa, red 5181-1263 (50/pk)
Column adapter parts
Silver seal 5182-9763 (5/pk)
Graphpak 2M inlet adapter, 0.20-mm id
*
5182-9754
Graphpak 2M inlet adapter, 0.25- to 0.33-mm id
*
5182-9761
