10 Maintaining the VI
Consumables and Parts for the Volatiles Interface
164 Maintaining Your GC
Consumables and Parts for the Volatiles Interface
See the Agilent catalog for consumables and supplies for a more complete listing, or visit the
Agilent Web site for the latest information (www.agilent.com/chem/supplies).
Table 27 Parts for the VI
Description Part number
Clamping plate G2319-20540
Volatiles interface G2319-60505
Long column nut (65 mm) G3504-20504
Nut, for transfer, pressure sensing, or split vent line 19258-20830
Ferrule, for transfer, pressure sensing, or split vent line 19258-20870
Split vent trap PM kit, single cartridge 5188-6495
Table 28 Nuts, ferrules, and hardware for capillary columns
Column id (mm) Description Typical use Part number/quantity
.530 Ferrule, Vespel/graphite, 0.8-mm id 0.45-mm and 0.53-mm capillary columns 5062-3512 (10/pk)
Ferrule, graphite, 1.0-mm id 0.53-mm capillary columns 5080-8773 (10/pk)
Ferrule, graphite, 0.8-mm id 0.53-mm capillary columns 500-2118 (10/pk)
Column nut, finger-tight (for
0.53-mm columns)
Connect column to inlet or detector 5020-8293
.320 Ferrule, Vespel/graphite, 0.5-mm id 0.32-mm capillary columns 5062-3514 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for
.100- to .320-mm columns)
Connect column to inlet or detector 5020-8292
.250 Ferrule, Vespel/graphite, 0.4-mm id 0.1-mm, 0.2-mm, and 0.25-mm capillary
columns
5181-3323 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for
.100- to .320-mm columns)
Connect column to inlet or detector 5020-8292
.100 and .200 Ferrule, Vespel/graphite, 0.37-mm id 0.1-mm and 0.2-mm capillary columns 5062-3516 (10/pk)
Ferrule, Vespel/graphite, 0.4-mm id 0.1-mm, 0.2-mm, and 0.25-mm capillary
columns
5181-3323 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Ferrule, graphite, 0.4-mm id 500-2114 (10/pk)
Column nut, finger-tight (for .100- to
.320-mm columns)
Connect column to inlet or detector 5020-8292
