13 Maintaining the NPD
Consumables and Parts for the NPD
210 Maintaining Your GC
Consumables and Parts for the NPD
See the Agilent catalog for consumables and supplies for a more complete listing, or visit the
Agilent Web site for the latest information (www.agilent.com/chem/supplies).
Table 34 NPD parts
Description Part number/quantity
Collector G1534-20530
Screw, M3 × 0.5 × 8 mm 0515-0655
NPD Blos bead assembly G3434-60806
Screw, M4 × 10 mm 0515-2495
J-clamp 1400-0015
NPD ceramic insulator kit
• Metal C-rings, top and bottom
• Ceramic insulators, upper and lower
5182-9722
NPD chemical sample kit solution of 0.65 ppm azobenzene, 1000 ppm octadecane,
1 ppm malathion in isooctane, 3 ampoules
18789-60060
NPD lid standoff G1534-20590
NPD raised jet weldment G4594-81000
Nut, 1/8-inch, brass, for packed column adapters 5180-4103 (10/pk)
Ferrule, Vespel/graphite, 1/8-inch, for packed column adapters 0100-1332 (10/pk)
Nut, 1/4-inch, brass, for packed column adapters 5180-4105 (10/pk)
Ferrule, Vespel, 1/4-inch, for packed column adapters 5080-8774 (10/pk)
1/8-inch Packed column adapter assembly G3435-81340
1/4-inch Packed column adapter assembly G3435-81330
Table 35 Nuts, ferrules, and hardware for capillary columns
Column id (mm) Description Typical use Part number/quantity
.530 Ferrule, Vespel/graphite, 0.8-mm id 0.45-mm and 0.53-mm capillary columns 5062-3512 (10/pk)
Ferrule, graphite, 1.0-mm id 0.53-mm capillary columns 5080-8773 (10/pk)
Ferrule, graphite, 0.8-mm id 0.53-mm capillary columns 500-2118 (10/pk)
Column nut, finger-tight (for
0.53-mm columns)
Connect column to inlet or detector 5020-8293
.320 Ferrule, Vespel/graphite, 0.5-mm id 0.32-mm capillary columns 5062-3514 (10/pk)
Ferrule, graphite, 0.5-mm id 0.1-mm, 0.2-mm, 0.25-mm, and 0.32-mm
capillary columns
5080-8853 (10/pk)
Column nut, finger-tight (for .100- to
.320-mm columns)
Connect column to inlet or detector 5020-8292
