2 Instrument Overview
Front inside view
18 Agilent 990 Micro GC User Manual
Front inside view
Unscrew and remove the front cover to view the channel cases and pump box.
See Removing the Covers on page 94.
Figure 3. Front inside view of the Agilent 990 Micro GC
Top assembly
Bottom assembly
Channel 1
Channel locking tabs
Pump box
Channel locking tabs
Channel 2
Sample inlet manifold
Second sample
manifold mount
Sample inlet
Sample inlet
Lock bar
Channel 2
Lock bar
