Agilent Technologies 990 - Rear Inside View

2 Instrument Overview
Rear inside view
Agilent 990 Micro GC User Manual 21
Rear inside view
To view the interior, unscrew and remove the rear covers. See Removing the Covers on page 94.
Figure 7. Rear inside view of the Agilent 990 Micro GC
Rear communication ports
(top assembly)
Gas connection adapter
Power connectors
Combined carrier gas
and vent plate
Gas connection adapter
CAN connection
between the GC and
Channel Extension Cabinet
